Flow Tech Flow Meter Solutions: Custom Industrial Fluid Balancing Skids for Plant Operations
Quick Answer: Flow Tech flow meter solutions for industrial balancing skids start with the right meter list. Silver Automation Instruments supplies Coriolis mass flow meters, electromagnetic flow meters, oval gear meters, and pressure transmitters with 4 to 20 mA HART output. We size them for DN15 to DN300 lines and typical accuracies from ±0.1 percent of rate. Send your pressure, temperature, pipe size, flow range, and fluid list and we will return a matched quote within 24 hours.
What Goes Into a Skid That Balances Fluids Correctly
A plant operations team often wants one panel that measures total mass in, total mass out, and line pressure. Here is the thing. The meter choice depends less on the skid frame and more on the fluid. But the meter choice is the expensive part. Conductive water and chemical lines use electromagnetic flow meters. Hydrocarbons, solvents, and polymers often need Coriolis or oval gear meters because volumetric meters cannot see density changes. Air and natural gas lines call for thermal mass or vortex meters.
We supply the metering side of the skid. A typical setup includes a Coriolis mass flow meter on the main feed, electromagnetic flow meters on water based additives, and oval gear meters on low flow dosing lines.
Meter Selection by Fluid and Process Condition
For a 50 mm water line with pressure around 6 bar and temperature at 25 °C, an electromagnetic flow meter with PTFE liner works well. It has no moving parts and measures down to 0.2 m/s.
For a resin line at 12000 cP and 50 °C, a Coriolis meter with DN15 to DN25 sensors gives direct mass flow in kg/h. It also reads density and temperature. That helps a plant operator catch a wrong solvent or a batch that is out of spec.
For diesel oil dosing from 0.5 to 20 L/h, an oval gear flow meter is a low cost choice. It is also easy to clean. We have supplied many of these to paint and lubricant blending customers in Southeast Asia and the Middle East.
Real Plant Scenarios We Have Seen
Last year a customer in Vietnam asked us to balance four chemical dosing lines on a water treatment skid. The fluids ranged from sodium hypochlorite to polymer. We used electromagnetic flow meters on the hypochlorite lines and oval gear meters on the polymer line. The PLC received 4 to 20 mA HART signals with totalized pulses.
A desalination plant in Oman needed a seawater intake meter for a balancing skid. The seawater conductivity was 52000 µS/cm and the line size was DN200. We supplied an electromagnetic flow meter with titanium electrodes and a pressure transmitter with a 0 to 10 bar range.
In Brazil, a food ingredients plant ran into drift on a thermal mass meter. The gas line pressure moved from 2 to 7 bar and the composition changed slightly. We replaced it with a vortex flow meter with an integrated PT100 temperature sensor and pressure compensation.
Parameters That Decide the Right Flow Meter
When you ask for a quote, do not start with a model number. Start with the process data. We need fluid name, viscosity in cP, conductivity in µS/cm if water based, flow range, pipe size in DN, pressure in bar, temperature in °C, and hazardous area classification.
Because a small error in viscosity can push you to the wrong meter type, we ask for it early. In practice, most engineers skip full cradle calculations and ask for a preconfigured skid. A balanced skid also needs the right signal output. We typically use 4 to 20 mA HART because most plant PLC and RTU systems accept it. For totalizing, pulse output is useful. For remote setup, we can add RS485 Modbus RTU.
FAQ: Skid Flow Meter Selection and Quotes
Q: Which flow meter works best for a chemical dosing skid?
A: For thin chemicals with conductivity above 5 µS/cm, an electromagnetic flow meter is common. For oils, polymers, or diesel, an oval gear meter handles viscosity up to 1000 cP and gives a local totalized reading.
Q: Can a Coriolis meter handle two fluids with different densities?
A: Yes. A Coriolis mass flow meter measures mass directly. It ignores density changes for a true mass balance. We often set the range in kg/h and send 4 to 20 mA HART to the PLC.
Q: Do I need ATEX approval?
A: If the skid sits in a solvent storage room or gas train, specify ATEX Zone 1 or Zone 2. Silver Instruments can supply ATEX approved Coriolis, electromagnetic, oval gear, and vortex meters with the certificates.
Q: What response time can I expect for a quote?
A: If you send pressure, temperature, pipe size, fluid, and flow range, we reply within 24 hours with model numbers and price.
Q: Do you supply only meters or the whole skid?
A: We supply the instruments and can preassemble them on a small panel or pipe spool. We do not fabricate large ASME pressure vessels but we work with local panel shops in your region.
Get a Skid Quote With Specific Model Numbers
Tell us the fluid and the operating window. Send pressure in bar, temperature in °C, pipe size in DN, flow range, and your preferred output. So we can send a quote with actual model numbers, not a brochure. Contact Silver Automation Instruments, Tel: +86 25 68650347, WhatsApp: +86 25 52155837, WeChat: +86 15365082610. You can also visit flow-meter.com.au for datasheets.
