1. Main Technical Parameters of High Voltage Electromagnetic Flow Meter

The main technical parameters of the High Voltage Electric Congsen Magnetic Flow Penetrating Meter are as follows: Execution Standard: According to JB/T000 Electromagnetic Flow Meter Standard. Nominal diameter: The DN series includes options from 5mm to 1200mm, while the rubber lining series has options from 10mm to 2000mm. Special specifications can be customized. Accuracy level: Two options are available: 0.5 level and 1.0 level. Working temperature: chloroprene rubber lining: 20 ℃ to+60 ℃. Polyurethane lining: 20 ℃ to+90 ℃. PTFE lining: 30 ℃ to+180 ℃. Work pressure: DN10 to DN65: 2.5Mpa. DN80 to DN150

1.6Mpa. DN200 to DN1600

1.0Mpa. Measurement range: The corresponding flow velocity range is 0.5m/s to 10m/s, and the conductivity requirement is greater than 20 μ s/cm. Output signal and load resistance: 0-10mADC, 0-1000 Ω, frequency 0-1000Hz, minimum load resistance not less than 10K Ω. 0/4-20mADC, 0-500 Ω, as well as 1-5V and 0-5V voltage output, also require a minimum load resistance greater than 10K Ω. Electrode material: 316 stainless steel. Protection level: Spring socks have IP65 and IP68 ratings. Power supply: Supports 220VAC ± 10%, 50Hz ± 5% AC, and 24VDC ± 10% DC. The length of the straight pipe section: at least 5DN is required upstream, and at least 3DN is required downstream. Connection method: flange connection is used, and the flange size complies with GB8 regulations. Environmental temperature: 25 ℃ to+45 ℃. Relative humidity: 5% to 95%. Total power consumption: less than 25W.

2. Technical parameters of electromagnetic flowmeter?

● Nominal Diameter Series DN (mm) Pipeline PTFE Lining: 10, 15, 20,

25, 32, 40, 50, 65, 80, 100, 125, 150, 200, 250, 300, 350, 400, 450, 500, 600 Pipeline Rubber Lining: 40, 50, 65, 80, 100, 125, 150, 300, 400, 500, 500, 600 Pipeline Rubber Lining: 40, 50, 65, 80, 125, 250, 300, 400, 500, 500, 500, 500, 1200 Note: Special specifications can be customized ● Flow Direction Forward, Reverse, Net Flow Rate, Range Ratio: 150:1 Repeatability Error: ± 0.1% of Measurement Value ● Accuracy Class: 0.5 Class, 1.0 Class ● Temperature Tolerance of Tested Medium: Ordinary Rubber Lining: -20~+60 ℃ High Temperature Rubber Lining: -20~+90 ℃ PTFE Lining: -30~+100 ℃ High Temperature Type B Vinyl lining: -30~+180 ℃ ● Rated working pressure: Pipeline type: DN10—DN65：≤2.5Mpa, DN80—DN150：≤1.6Mpa, DN200—DN1200：≤1.0Mpa ● Flow measurement range: Flow measurement range: Flow velocity range is 0.3-15m/s ● Conductivity range: The conductivity of the measured fluid is ≥ 5 μ s/cm. Most media composed of water have a conductivity in the range of 200-800 μ s/cm, and electromagnetic flow can be used; ● Output current and load resistance: 4~20mA Fully isolated load resistance ＜ 750 ohms Pulse Lao Tan Sen frequency 0-1KHZ Optoelectronic isolation OCT External power supply ≤ 35V Maximum collector current when conducting: 25mA ● Electrode material: Stainless steel containing molybdenum, titanium (Ti), tantalum (Ta), Hastelloy (H), platinum (Pt) or other special electrode materials ● Protection level: Submersible type: IP68, other types IP65 ● Power supply: 85~265V, 45~63HZ ● Straight pipe length: Pipeline type: Upstream ≥ 5DN, downstream ≥ 2DN ● Connection method: Flange connection is used between the flowmeter and the piping, and the flange connection size should comply with the provisions of GB9119-88. ● Anti riot sign:
