1. What are the types of air flow meters?

There are mainly the following types of air flow meters: blade type air flow meter. Features: simple structure, high reliability.. Disadvantages: Large size, high intake resistance, slow response. Karman vortex air flow meter: Principle: When a cylindrical or triangular object is placed in a fluid, two columns of vortices with opposite rotation directions and alternating appearance will be generated downstream. Optical Karman vortex air flowmeter: Principle: Utilizing the changes in air pressure on both sides of the vortex generator, it vibrates on the metal foil through a guide hole. The light emitted by the light-emitting diode shines on the vibrating metal foil, and the reflected light received by the phototransistor is modulated by vortices. After demodulation, the frequency modulated beam rate signal representing the air flow rate is obtained. Ultrasonic shock wave type Karman vortex air flowmeter: Principle: Install ultrasonic transmission probes and reception probes on opposite sides of the downstream pipeline of the Karman vortex generator. The influence of Karman vortex on air density can cause a phase difference in the time of ultrasonic waves from the transmitting probe to the receiving probe. Processing this phase signal can obtain the vortex pulse signal.

2. What are the classifications of air flow meters?

Commonly used air flow meters include: blade type air flow meter, Karman vortex type air flow meter, hot wire type air flow meter, and hot film type air flow meter.

; An air flow meter is a flow meter that measures flow based on Faradays law of electromagnetic induction. The advantages of an air flow meter are minimal pressure loss What are the types of air flow meters

and a wide range of measurable flow rates. The ratio of the maximum flow rate to the minimum flow rate of an air flow meter is generally 20:1 or above, and it is suitable for a wide range of industrial pipe diameters, up to 3 meters. The output signal is linear with the measured flow rate, and the accuracy is high. It can measure the fluid flow rate of acid, alkali, salt solutions, water, sewage, corrosive liquids, as well as mud and slurry with a conductivity of 1 microsecond per centimeter or more. However, an air flow meter cannot measure the flow rate of pneumatic vesicles, steam, and purified water. An air flow meter is a device that converts the amount of air drawn in into an electrical signal. The advantages of an air flow meter are minimal pressure loss and a wide range of measurable flow rates. The ratio of the maximum flow rate to the minimum flow rate of an air flow meter is generally above 20:1, and it is suitable for a wide range of industrial pipe diameters, up to 3m. The output signal is linear with the measured flow rate and has high accuracy. It can measure the fluid flow rate of acid, alkali, salt solutions, water, sewage, corrosive liquids, as well as mud and slurry with conductivity ≥ 1 μ s/cm. But air flow meters cannot measure the flow of gas, steam, and purified water. During the use of an air flow meter, the gas flow passes through the meter and drives the turbine blades to rotate. The number of revolutions of the impeller is directly proportional to the volume of gas passing through the air flow meter. There is a specially designed patented guide frame installed at the inlet of the flowmeter, which accelerates the airflow entering the flowmeter as the flow rate increases. The design of the guide
