1. Introduction to the Uniformity Tube Flow Meter

The Annubar Flow Meter (also known as the Flute Uniformity Tube Flow Meter or Toba Tube Flow Meter) is a differential pressure flow meter. The Anuba flowmeter uses the pitot tube measurement principle to measure the pressure difference between the dynamic pressure upstream of the baffle and the static pressure downstream, in order to achieve the purpose of measuring flow rate. Measure the diameter of the pipeline between DN20 and DN12000. Anuba flowmeter is mainly used for measuring various energy sources such as liquids, fuel gases, vapors, and gases in industrial processes, with high stability and repeatability. The design theory conforms to the Bernoulli equation principle and can be verified using the JJG/640-90 standard. The Anuba flowmeter has become an ideal product to replace orifice plates due to its simple installation, low pressure loss, high strength, resistance to wear and tear, and no leakage. It can be widely used for flow measurement of blast furnace gas, compressed air, steam, and other liquids and gases in industrial and mining enterprises. The unique internal quadratic average structure provides high accuracy (± 1% reading) and high repeatability (± 0.1%). The outer impact tube is made of a single piece of material without welding, which naturally has the highest strength compared to similar products welded by a double body structure. It is also easy to choose materials that are resistant to high temperatures and corrosion. The honeycomb hexagonal stable structure produces a unique beam distribution shape, ensuring the stability of low-voltage signals and generating a higher differential pressure than similar products, improving the range rat

io. B is suitable for square or rectangular pipes. For the inevitable blockage problem of similar products when measuring dirty media, there are online pull-out models or manual and automatic blowing solutions and devices available to achieve non-stop maintenance. The D-speed averaging tube, three valve group, temperature and pressure compensation, and transmitter form an integrated structure that is easy to use. E has no drift in flow coefficient and is stable for a long time. F exclusively provides intuitive resonance verification to ensure long-term stable operation. G has low pressure loss, low energy consumption, and significant energy-saving effect. It is easy to install, saves labor, and has a low price. Overview of the averaging tube flowmeter: The averaging tube flowmeter has become an ideal product to replace orifice flow meters due to its simple installation, low pressure loss, high strength, no wear and tear, and no leakage. Anuba flowmeter can be widely used for flow measurement of blast furnace gas, compressed air, steam and gas in industrial and mining enterprises. Technical parameters of the averaging tube flowmeter:

1. Specification: DN50-DN5000 (mm); Insertion type: DN500-DN5000 (mm);

2、 Measurement accuracy: ± 6.0%; Repeatability: ± 0.1%;

3、 Range: Volume flow rate: 10:1; Quality flow rate: 8:1;

4、 Work pressure: The average speed tube is not functioning properly. Type: ≤ 20MPa; Adjustable type of averaging tube: ≤ 10MPa;

5、 Fluid temperature: ≤ 450 ℃;

6、 Medium viscosity: ≤ 30CP (equivalent to heavy oil);

7、 Material: Annubar sensor, three valve group, stainless steel (optional); Main pipe and flange: stainless steel or carbon steel (optional); The worki
