1. Main technical parameters of metal rotor flowmeter

(1) Basic measurement range: Water (20 ℃) 2.5-150000L/h Air (20 ℃ key type, 0.1013MPa) 0.07-4000Nm3/h Range ratio: 10:1 Accuracy

1.5/2.5 Working pressure: ≤ 6.4MPa Working temperature: -40~350 ℃ (fluoroplastic lining -10~80 ℃) Environmental temperature: -20~80 ℃ Medium viscosity: DN15 ≤ 5mPa. SDN25~DN150 ≤ 250mPa. S Pipe body material: 1Cr18Ni9Ti, 316L, lined with PTEF, etc. Process connection: flange, or according to the steam provided by the user. Head: flange, DN15/PN1.6， Or as provided by the user

(2) Remote transmission device ① GD 5W1-1 angular displacement transmitter basic error

1.5% F.S output signal: 4-20mA load impedance: 350 Ω power supply voltage: 24VDC ambient temperature: -30~80 ℃ outlet: M20 × 1.5 explosion-proof mark: ExibIICT4 ② GD E-HD transmitter power supply influence:<0.1% (excluding digital resolution [70 μ A]) load influence:<0.1% (excluding digital resolution [70 μ A]) current loss: 4-21.6mA, 0% relative to the measured value load impedance: 0-800 Ω working voltage: 12.8-30VCD two-wire Rext [K Ω]=(Power supply [V] -12.7)/22mA output signal: 4-20mA ambient temperature: -25~80 ℃ outlet: M20 × 1.5 explosion-proof mark: ExibIICT6 measurement range: water (20 ℃) 2.5-150000L/h, air (20 ℃, 0.1013MPa) 0.07-4000Nm3/h range ratio: 10:1 accuracy

1.5/2.5 Working pressure: ≤ 6.4MPa Working temperature: -40~350 ℃ (fluoroplastic lining -10~80 ℃) Environmental temperature: -20~80 ℃ Medium viscosity: DN15 ≤ 5mPa. S, DN25~DN150 ≤ 250mPa. S Pipe body material: 1Cr18Ni9Ti, 316L, lined with PTEF, etc. Process connection: flange, or according to the users preferred steam sleeve: flange, DN15/PN1.6， Or according to the speci

fications provided by the user for the LZ series metal rotor flowmeter: through diameter (mm) flow range pressure loss kPa water L/h * air M3/h * water air conventional type anti-corrosion conventional type, Anti corrosion type 15 2.5~25---0.07~0.7 6.5 7.1 4.0~40 2.5~25 0.11~1.1 6.5 7.2 6.3~63 4.0~40 0.18~1.8 6.6 7.3 10~100 6.3~63 0.28~2.8 6.6 7.5 16~160 10~100 0.40~4.0 6.8 8.0 25~250 16~160 0.7~7.0 7.2 10.8 40~400 25~250 1.0~10 8.6 10.0 63~630 40~400 1.6~16.0 11.1 14.0 25 100~1000 63~630 3~30 7.0 7.7 160~1600 100~1000 4.5~45 8.0 8.8 250~2500 160~1600 7~70 10.8 12.0 400~4000 250~2500 11~110 15.8 19.0 40 500~5000---12 ～ 120 10.8 9.8 600 ～ 6000---16 ～ 160 12.6 16.5 50 630 ～ 6300 400 ～ 4000 18 ～ 180 8.1 8.6 1000 ～ 10000 630 ～ 6300 25 ～ 250 11.0 10.4 1600 ～ 16000 1000 ～ 10000 40 ～ 400 17 .0 15.5 80 2500～25000 1600～16000 60～600 8.1 12.9 4000～40000 2500～25000 80～800 9.5 18.5 100 6300～63000 4000～40000 100～1000 15.0 19.2 150 20000～100000 --- 600～3000 19.2 20.3

2. Detailed explanation of the usage steps of Cologne metal tube rotor flowmeter

The use of Cologne metal tube rotor flowmeter requires strict adherence to operating specifications, with the core being installation compliance, flow control stability, and continuous operation monitoring. 1. Preparation for appearance and matching inspection before installation: Before use, it is necessary to confirm that the appearance of the flowmeter is not damaged or deformed, and that the flange or threaded interface is not loose. Special attention should be paid to whether the medium type, temperature, and pressure range on the flowmeter label match the on-site working conditions, in order to avoid damage caused by excessive use. Flow direction and
